Facilities

Sr. No. Machine Name Capacity
1 SURFACE GRINDING MACHINE MAKE – WALDRICH COBURG 3000X1250
2 WMW SLIDEWAY GRINDING 3500X2000X1500
3 WMW SURFACE GRINDING 2500X6000X1200
4 SURFACE GRINDING MACHINE MAKE - CAMUT 2000 X 600
5 DOUBLE COLUMN VMC MAKE - HAMUEL 6500X2500X1200
6 DOUBLE COLUMN VMC MAKE- WALDRICH COBURG 4000X1500
7 DOUBLE COLUMN VMC MAKE - TOS 4000X2000X1200
8 DOUBLE COLUMN VMC MAKE - AWEA 5000X2000X1000
9 DOUBLE COLUMN VMC MAKE - INGERSOLL BOHLE 5000X2000X1200
10 DOUBLE COLUMN VMC MAKE - JOHNFORD 8000 x 4300 x 1066
11 DOUBLE COLUMN VMC 2 HEADS MAKE - JOHNFORD 8000 x 4300 x 1066
12 VMC MAKE - PINNACLE 2000X300X600
13 VMC MAKE - MIKRON-VC 1000 1000X60X60
14 CNC BED TYPE MILLING MACHINE MAKE - BUTLER 4000X1000X1200
15 FLOOR BORING MAKE - FLORIEP 3500X1800X1000
16 HORIZONTAL BORING MACHINE MAKE - PFEIFER 600X1000X800
17 TURNING CENTER - MAKE BOEHRINGER DIA.800 &LENGTH 2500
18 CNC LATHE MACHINE MAKE - GEMINI DIA 800 mm X 3000 mm
19 LATHE MACHINE MAKE - VIKRAM CENTRE HEIGHT-190 CHUCK DIA.-300 BETWEEN CENTRE- 1400
20 LATHE MACHINE MAKE - MYSORE KIRLOSKAR CENTRE HEIGHT-240 CHUCK DIA.-300 BETWEEN CENTRE- 850
21 RADIAL DRILLING MACHINE MAKE - MAS VR4 SPINDLE DIA. 70
22   RADIAL DRILLING MAKE - HMT SPINDLE DIA. 82
23 RADIAL DRILLING MAKE - CSEPEL SPINDLE DIA. 85
24 CNC DEEP HOLE DRILLING MACHINE MAKE - LOCH) Dia 120 mm x 2000 mm
25 CNC DEEP HOLE DRILLING MACHINE MAKE - HEGENGGHEIDT Dia 120 mm x 2000 mm
26 MILLING MACHINE MAKE - HURON 750X500X250
27 BANDSAW MACHINE DIA 300 mm

SR. NO. MACHINE TYPE MADE SPECIFICATION (mm) ACCURACY / MTR
1 SURFACE GRINDING

SURFACE GRINDING
Waldrich Coburg German Make Table Size – 3000 x 1000
Grinding Capacity - 3000 x 1250
0.01
2 SLIDEWAY GRINDING

SLIDEWAY GRINDING
WMW
German Make
Size Grinding Capacity
3500 x 2000 x 1500
0.01
3 SURFACE GRINDING

SURFACE GRINDING
WMW
German make
GRINDING CAPACITY
2500 x 6000 x 1200
0.01
4 HORIZONTAL BORING
HORIZONTAL BORING
Toss Table Size - 1250 x 1250
X Axis  -   1750
Y Axis  -   1200
Z Axis  -   1500
W Axis -     900
0.03
5 Pfeifer Table Size - 1000 x 900
X Axis  -   600
Y Axis  -    1000
Z Axis  -   800
0.03
6 PLAINO MILLING MACHINE

PLAINOMILLERS
Waldrich coburg Table size - 4000 X 1500 0.05
7
CNC Bed Type Milling Machine
Butler
X - 4000 mm
Y - 1000 mm
Z - 1200 mm
0.01
8
MILLING

MILLING HURON
HURON
750 x 500 x 250
0.05
9
VMC

VMC Awea
Awea
X - 5000 mm
Y - 2000 mm
Z - 1000 mm
10
Radial Drilling Machine

Radial Drilling Machine
Csepel
Spindle Dia 85 mm
11
VMC

VMC Hamuel Make
Hamuel Make
X - Axis - 6.5 Mtr
Y - Axis - 2.5 Mtr
Z - Axis - 3 Mtr
0.02
12
Boehringer Turning CNC
Boehringer
Swing over dia 1100 mm Maximum Lengh achieved 2.5 Mtr.
0.01
13
Radial Drilling Machine

Radial Drilling Machine MAS VR4
MAS VR4
Spindle Dia 70 mm


Handling Facilities And Instruments



1.
Over Head Crane - 10Tons
Over Head Crane - 5 Tons
  1 No.
  7 No.
2.
Major Surface Plates of GMT make
2000 mm x 1000 mm             Granite
1800 mm x 1000 mm              C.I.
1000 mm x 1000 mm              C.I.
  1 No.
  1 No.
  1 No.
3.
Master square of size-300 mm x 500mm
Master square of size-300 mm x 300mm
  1 No.
4.
Height gauges up to 1000 mm
2 Nos.
5.
Height Master  : Accurate Make
0 to 600 mm
6.
Precision Level Bottle
03Nos.
7.
Vernier Calipers
Up To 1000 mm
8.
Micrometers
Up To 2000 mm
9.
Dial Bore Gauges
06 Nos.
10. 2 D co-ordinate measurement (Trimos Make)
1000 mm
